Magnetic Incremental 4096 CPR or Absolute Single turn encoder
Protective functions
Over current, over/under voltage, overheating, short circuit
Debug & configuration
Serial Interface (not for M-C)
Digital Inputs
4 not isolated 5-24Vdc PNP
Analog Inputs
2 with potentiometer or 0-10Vdc not isolated
Digital Outputs
2 not isolated open drain, 5-24Vdc 100mA
Technical Files
Datasheet
Short manual
3D STP file
Custom combinations are available on request. Contact us
Gearboxes
GP80 -T - Torque
Planetary gearboxes - GP series
Size (mm)
80
Length (L) (mm)
103,5 - 129
Reduction Ratio
3,33 - 66,62
Nominal Output Torque (Nm)
10,58 - 47,85
Max. Input Speed (rpm)
3184 - 7000
DL Space
DL Space is the innovative visual programming environment for our drivers. This software does not require the learning of a text language but, through a graphic programming and guided windows, it allows the creation of multitasking programs exploiting all the functionalities of the DL drives with S200 firmware.
The programs realized with DL Space allow to exploit all the low-level control modes of our programmable drives for both brushless and stepper motors, including multiple homing modes, the electric shaft, the electronic range and many other functions.
Application debugging can be carried out quickly and easily thanks to the dedicated windows that include a virtual oscilloscope to monitor the actual motor movements.
Software
Manual
Service SCI Interface cable is required to use our Software and available on request.
Connector kit is not included but available on request.
